Welding edge :3 sides of each end of the beam
Speed : 3 pieces in 2 min
Length of the beam : 1200-3800mm
Connector thickness : 3mm
Diameter of the welding wire : 0.8-1.0mm
| 1 | Welding edge | 3 sides of each end of the beam |
| 2 | Speed | 3 pieces in 2 min |
| 2 | Length of the beam | 1200-3800mm |
| 3 | Connector thickness | 3mm |
| 4 | Diameter of the welding wire | 0.8-1.0mm |
| 5 | Model of the welding unit | TC-315F IGBT (Chinese brand Aotai) |
| 6 | Number of welding unit | 4 sets |
| 7 | Main motor | 2kwX2 stepping motor |
| 8 | Voltage | 220v, 60HZ, 3 phase |
| 9 | Clamping | By pneumatic |
| 10 | Turn over system | By cylinder, gear and rack |
| 11 | Horizontal push to adjust the length | By liner guide way and fix by manual |
| 12 | Size of the machine | About 5.2mX1mX1.9m |
| 13 | Machine weight | About 1200kgs |
Brand list:
| 1 | PLC | Delta |
| 2 | Touch screen | delta |
| 3 | Air cylinder | AirTac |
| 4 | Relay and switch | Schneider |
